small diameter ERW square tube with mild steel Q235

Large Image : small diameter ERW square tube with mild steel Q235

Product Details:

Place of Origin:	China
Brand Name:	Huibo
Certification:	ISO

Payment & Shipping Terms:

Minimum Order Quantity:	30MT
Price:	FOB,CIF,CFR
Packaging Details:	in bundles or in bulk
Delivery Time:	10-15days after we get the down payments
Payment Terms:	TT/LC
Supply Ability:	5000MT/MONTH

Contact Now

Detailed Product Description

Square Tube is one of the main steel pipes used in construction field and machinery industry.

In general, square tubes can be divided into 2types : seamless & ERW .

From technical pespective, it can be categoried into: cold rolled & hot formed.

Standards: GB/T3094-2000, GB/T6728-2002, JISG 3466, EN10219, EN10210, ASTM A500,

——Specification Range

Normal Size

Dia(mm)	T(mm)	Dia (mm)	T(mm)	Dia (mm)	T(mm)
30*30	2-4	120*120	2-14	250*250	8-25
40*40	2-4	125*125	2-14	255*255	8-25
50*50	2-5	130*130	2-14	258*258	8-25
60*60	2-5	135*135	8-14	260*260	8-25
70*70	2-5	140*140	8-20	280*280	8-25
75*75	2-5	150*150	8-22	300*300	9-25
80*80	2-8	160*160	8-22	350*350	9-25
90*90	2-9	180*180	8-22	360*360	9-25
100*100	2-14	200*200	8-25	400*400	9-25
110*110	2-14	220*220	8-25
115*115	2-14	240*240	8-25

Dia(mm)	T(mm)	Dia(mm)	T(mm)	Dia(mm)	T(mm)
60*20	2-3	80*40	2-6	110*60	5-8
60*30	2-3	90*40	2-6	110*70	5-10
60*40	2-6	90*50	2-6	120*60	5-8
70*20	2-3	100*20	2-4	120*80	5-10
70*30	2-3	100*30	2-4	120*100	5-14
70*40	2-6	100*40	2-4	125*90	5-10
70*50	2-6	100*50	2-6	125*100	5-14
75*45	2-6	100*80	4-9	130*120	5-14
				140*80	5-6,8-10

Big Size

Dia (mm)	T(mm)	Dia (mm)	T(mm)	Dia (mm)	T(mm)
180*100	5-14	300*200	7-25	400*250	7-20
200*100	6-18	300*250	7-25	400*300	7-25
200*150	5-6,8-25	320*200	7-25	420*350	7-25
250*100	5-14	350*100	7-18	450*150	7-18
250*200	6-25	350*200	7-25	450*250	7-22
250*225	6-25	350*250	7-25	500*300	7-25
300*100	7-18	350*300	7-25	600*200	7-18
300*150	7-18	400*200	7-18	600*400	8-25
